20M HD All-in-One BNC and Power CCTV Cable for Camera and DVR

The all-in-one format combines the RG59 coaxial video conductor and 12V DC power lead in a single cable assembly with pre-fitted BNC connectors for video and DC connectors or flying leads for power. This combined format reduces the cable routing work compared to running separate video and power cables.

At 20 metres, the cable is the longer all-in-one option compared to the 10m version available in this range. Twenty metres suits cameras positioned in adjacent rooms, above doorways on the next room or floor from the DVR, or at positions where the 10m cable falls just short.

The HD designation indicates the cable’s shielding and conductor specification is appropriate for HD analogue signal transmission (HDCVI, AHD, TVI) at the 5MP and 8MP resolutions used by current-generation DVRs and cameras.

For runs beyond 20 metres, the recommended approach is a separate RG59/2 coaxial cable drum with power run separately, which provides better signal integrity over longer distances than a single pre-made assembly.

For CCTV installers completing 20-metre camera connections across London and the UK, the HD-BNC-20M provides the ready-made BNC and power cable for this length.

Key Features

• 20 metre all-in-one BNC and power cable for CCTV camera connections
• Combined coaxial video (BNC) and 12V DC power in one cable
• HD-rated: suitable for HDCVI, AHD, TVI, and CVBS cameras
• Longer option than 10m cable: for cameras at 20m from DVR
• Ready-made with pre-fitted BNC connectors at both ends
• For runs over 20m use separate RG59/2 coax with independent power
